• Model NO.：L160-12
• Type：Top-Slewing Crane
• Rated Lifting Moment：2500kn.M
• Max. Hoisting Capacity at Jib Tip：9.57t
• Max. Free-Standing Height：49.7m
• Max. Working Height of Anchored Crane：194.5m
• Hoisting Mechanism Power：60kw
• Hoisting Mechanism Rope Capacity：1010m
• Transport Package：Nude
• Specification：12000kg
• Trademark：xcmg
• Origin：Hunan China
• HS Code：84262000
• Production Capacity：500 Per Units

Rated lifting    moment (kN.m)2500 Max. lifting    height (m)Free-standing    stationary crane49.7Anchored crane194.5Working radius    (m)     Max. working    radius   50Min. working    radius    2.8Max. lifting    capacity (t)12       Hoisting    mechanism Rope    fallα=2α=2.5α=4Speed (m/min)0~480~960~1200~320~640~800~240~480~60Lifting weight    (t)52.51.257.53.751.8751052.5Speed (m/min)0~530~1060~1600~35.50~710~106.50~26.60~530~80Lifting weight    (t)631.594.52.251263Power (kW)60, 63Slewing    mechanismSpeed (m/min)0~0.7, 0~0.68Power (kW)2×95N.m(Equal to 2×5.5kW).Trolleying    mechanismSpeed (m/min)1.7(15°~84.5°)Power (kW)45
