| Item | Unit | Value |
| Working performance | Max. rated lifting capacity | kg | 55000 |
| Max. load moment of basic boom | kN.m | 2009 |
| Max. oad moment of main boom(fully extended) | kN.m | 1050 |
| Max. load moment of basic boom | m | 12.6 |
| Max. lifting height of main boom | m | 43.6 |
| Max. lifting height of jib | m | 59.5 |
| Working speeds | Max. hoist rope speed(Main winch) | m/min | 120 |
| Max. hoist rope speed(Auxiliary winch) | m/min | 120 |
| Boom demrricking up time | s | 50 |
| Boom demrricking up time | s | 95 |
| Slewing speed | r/min | 0-2.2 |
| Driving | Max. driving speed | km/h | 76 |
| Max. gradeability | % | 40 |
| Turning diameter | m | ≤24 |
| Min. ground clearance | mm | 260 |
| Oil consumption per hundred kilometers | L | 43 |
| Mass | Deadweight in driving condition | kg | 42000 |
| Complete vehicle kerb mass | kg | 41870 |
| Front axle load | kg | 16000 |
| Rear axle load | kg | 26000 |
| Dimension | Overall dimensions(L×W×H) | mm | 13700×2800×3650 |
| Longitudinal distance between outriggers | m | 5.92 |
| Transversal distance between outriggers | m | Fully extended:7.1, |
| Intermediately extended:4.8 |
| Tail slewing radius | mm | 3900 |
| Main boom length | m | 11.4 - 43.0 |
| Main boom angle | ° | -2 - 80 |
| jib length | m | 9.5,16.0 |
| Offset | ° | 0,30 |
