Item | Unit | Specification |
---|
Max. rated lifting capacity | Basic-form main boom | t | 100 |
Stationary auxiliary boom | t | 15.6 |
Max. Lifting Torque | t.m | 575 |
Length of Main Boom | m | 19~73 |
Luffing Angle of Main Boom | Working Condition of Main Boom | ° | 30~ 81 |
Working Condition of Stationary Auxiliary Boom | 30~ 81 |
Length of Stationary Auxiliary Boom | m | 13~25 |
Max. Single Rope Speed of Hoisting Mechanism (Non-load, Fourth Layer) | m/min | 110 |
Max. Single Rope Speed of Main Boom Luffing Mechanism (First Layer) | m/min | 34 |
Max. Slewing Speed | r/min | 1.4 |
Max. Traveling Speed | km/h | 1.3 |
Gradeability | % | 30 |
Average Ground Pressure | MPa | 0.087 |
Engine Power | kW | 206 |
Overall Weight (Main Hook, Full Counterweight, 19m Boom) | t | 104.5 |
Max. Mass of Single Piece in Transport State | t | 32.5 |
Max. Size of Single Piece in Transport State (L × W × H)
|
