• Model NO.：SCC1000A
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Straight Arm
• Rated Load：100ton
• Color：Yellow
• Boom Length：18072m
• Usage：Construction
• Transport Package：Nude Package
• Specification：ISO
• Trademark：EON
• Origin：Jiangsu, China (Mainland)
• HS Code：8701200000
• Production Capacity：1000 Units, Year

Max. lifting capacity
 Boom
 t
 100
 Jib
 t
 11
 Max. load moment
 kN.m
 5395
 Boom length
 m
 18~72
 Boom elevating angle
 °
 0~80°
 Fixed jib length
 m
 12~24
 Fixed jib offset

 10°,30°
 Max. single line hoist speed (at 5th layer with no load)
 m/min
 100
 Max. single line elevating speed (at 5th layer with no load)
 m/min
 45
 Max. swing speed
 r/min
 1.4
 Travel speed
 km/h
 1.1
 Min. elevating time
 s
 240
 Winch hoist speed(with full load)
 m/min
 4
 Max. grade-ability

 30%
 Mean ground pressure
 MPa
 0.0927
 M11-C250 Engine output
 kW
 184
 Total mass (main hook block,18m boom)
 t
 114
 Max. base machine weight for transport
(without counterweight, L/R crawler, lattice boom)
 t
 40.0
 Max. base machine dimension for transport (L×W×H)
 m
 9.6×3.3×3.3
