8ton Mobile Small Truck Cranes Qy8b. 5 Cheap Price
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service:1 Year
- Warranty:1 Year
- Certification:GS, RoHS, CE, ISO9001, ISO9001: 2000
- Condition:New
- Maximum Lifting Height:20-25m
- Maximum Lifting Weight:8-10t
Base Info
- Model NO.:QY8B. 5
- Shaft Number:2
- Crane Jib:Two-Arm
- Type:Bridge Crane
- Rated Load 8ton:Fully Extended Boom+Jib 25.3m
- Application:Construction Usage
- Tower Crane Type:Under Slewing Cranes
- Sling Type:Wire Rope
- Main Girder Form:Double Girder
- Power Source:Electric
- Moving Type:Orbital
- Installation:Assembled
- Transport Package:Suitable Package for Shipment
- Specification:ISO
- Trademark:EON
- Origin:Xuzhou, China
- Production Capacity:150PCS,Month
Description
Basic Info.
Model NO. QY8B. 5 Shaft Number 2 Crane Jib Two-Arm Type Bridge Crane Rated Load 8ton Fully Extended Boom+Jib 25.3m Application Construction Usage Tower Crane Type Under Slewing Cranes Sling Type Wire Rope Main Girder Form Double Girder Power Source Electric Moving Type Orbital Installation Assembled Transport Package Suitable Package for Shipment Specification ISO Trademark EON Origin Xuzhou, China Production Capacity 150PCS/MonthProduct Description
8ton Mobile Small Truck Cranes QY8B. 5 cheap priceSpecifications
8 ton mobile truck crane QY8B. 5
Rated load 8ton
Fully extended boom+jib 25.3m
Total weight in travel 10490kg
Dimension
Unit
QY8B.5
Overall length | mm | 9450 |
Overall width | mm | 2400 |
Overall height | mm | 3180 |
Weight | ||
Total weight in travel | kg | 10490 |
Front axle load | kg | 2800 |
Rear axle load | kg | 7690 |
Power | ||
Engine model | YC4E140-30 | |
Engine rated power | kW/(r/min) | 105/2500 |
Engine rated torque | N.m/(r/min) | 500/1600 |
Travel | ||
Max. travel speed | km/h | 75 |
Min. turning diameter | mm | 16000 |
Min. ground clearance | mm | 260 |
Approach angle | ° | 29 |
Departure angle | ° | 11 |
Max. grade ability | % | 28 |
Fuel consumption for 100km | L | 25.5 |
Main performance | ||
Max. rated total lifting capacity | t | 8 |
Min. rated working radius | m | 3 |
Turning radius at turntable tail | m | 2.254 |
Max. lifting torque | KN.m | 245 |
Base boom | m | 8.2 |
Fully extended boom | m | 19 |
Fully extended boom+jib | m | 25.3 |
Longitudinal outrigger span | m | 3.825 |
Lateral outrigger span | m | 4.18 |
Working speed | ||
Boom luffing time | s | 28 |
Boom full extension time | s | 31 |
Max. swing speed | r/min | 2.8 |
Main winch single-pump/dual-pump converging (single rope) | m/min | 53/110 |
