13ton Telescopic Truck Mounted Crane Spk38502 for Paraguay
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：20-25m
- Maximum Lifting Weight：14-16t
- Shaft Number：3
- Crane Jib：Four-Arm
Base Info
- Model NO.：SPK38502
- Type：Straight Arm
- Max. Lifting Capacity：20t
- Boom Length：21.6m
- Max.Lifting Height：22.4m
- Engine Model：Wd615.87
- Rated Power：213kw
- Transport Package：Nude Packing or by Container
- Specification：11984mmx2496mmx4021mm
- Origin：Hunan, China
- HS Code：8426910000
- Production Capacity：100units, Month
Description
Capacity
Max. gradeability
Max. lifting capacity
33%
20t
Main Performance
Dimensions
Rated lifting moment
Overall length
50mt
11984mm
Rated lifting capacity
Overall width
2000kg(2.5m)
2496mm
Max.outreach
Overall height
21.2m
4021mm
Max.lines of hook
Axles
6
4
Slewing angle(continuous)
Axle distance-1,2
continuous
1800mm
Boom raising angle
Axle distance-2,3
0°~75°
4575mm
Max.lifting height(the measurement from the ground after the outriggers fully extended)
Axle distance-3,4
22.4m
1400mm
Length of the basic boom
Weight
6.25m
Overall weight
Length of fully extended boom
45000kg
21.6m
Front axle load
Boom sections
15000kg
5
Rear axle load
Outrigger span (fully extended)
30000kg
7.25m
Engine
Recommended volum for the system
Model
100L/min
WD615.87
Operating pressure
Rated power
29/32Mpa
213Kw
Oil tank capacity
Rated torque
300L
1160Nm at 1100~1600 rpm
Crane moment (dynamic)
Emission standard
913.8kNm/93.1mt
Euro II
Torsional moment (dynamic)
Traveling
52.5kNm/5.4mt
Max. traveling speed
Aircondition
102km/h
HVAC in low cab
Approach angle
Cooling / Heating
16°
Departure angle
14°
