Famous Brand 50 Ton Truck Crane Qy50ka Hot Sale

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：30-40m
  • Maximum Lifting Weight：>16t
  • Shaft Number：4
  • Crane Jib：Two-Arm

Base Info

  • Model NO.：QY50KA
  • Type：Folding
  • Max. Rated Lifting Capacity：25000kg
  • Max. Lifting Height of Jib：46.58m
  • Transport Package：Comply with Export Packaging Requirements for Min
  • Specification：12700*2500*3450 mm
  • Trademark：Sinomada
  • Origin：China
  • HS Code：84262000
  • Production Capacity：100 Units Per Month

Description

DimensionsOverall length13770mmOverall width2800mmOverall height3570mmWeightDead weight in travel state41000Kg1st axle load7500Kg2nd axle load7500Kg3rd axle load13000Kg4th axle load13000KgPowerEngine modelWD615.334 WD615.338 WP10.336 WP10.375 Engine rated output247/2200 276/2200 247/2200 275/2200Kw(r/min)Engine rated torque1350(1300~1600) 1500(1300~1600) 1350(1100~1500) 1460(1200~1600)N.m(r/min)TravelMax.travel speed80Km/hMin.turning diameter24mMin.ground clearance291mmApproach angle17.Departure angle11.Max.gradeability40%Fuel consumption of per 100km42LLifting performanceMax.total rated lifting load50tMin. working radius3mmTurning radius at swing table tail3482mBase boom max.load moment1822Kn.mBase boom11.3mFull- extended boom42.7mFull-extended boom+ jib57.7mOutrigger longitudinal distance span5.91mOutrigger lareral distance span6.9mWorking speedBoom elevating time40sBoom telescoping time80sMax. slewing speed2r/minMain winch max. speed(no load)130m/minAuxiliary winch max. speed(no load)120m/minFamous Brand 50 Ton Truck Crane Qy50ka Hot Sale
