• Model NO.：Crawler Crane
• Specification：CE
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000PCS,Year

ItemsUnitParameter value Performance parameters *Max. rated lifting load of main boom(t)55Max. rated lifting load of fixed jib(t)11.4Max. rated lifting load of luffing jib(t)-Max. lifting load moment(t.m)203.5Max. lifting load of tower jib(t)-Max. rated lifting load of boom single pulley (t)6Max. rated lifting load of special jib(t)-Size *Main boom length(m)13~52Main boom luffing angle(°)-3~80Fixed jib length(m)7~16Tower jib length(m)-Max. size of single unit for transport (L×W×H)(m)12.04×3.45×3.36Installation angle of fixed jib(°)10,30Special jib length(m)-Speed *Max. single line speed of hoist system(m/min)125Max. single line speed of main luffing system(m/min)87/78Max. single line speed of jib luffing system(m/min)-Max. slewing speed(r/min)2.45/2.2Max. travel speed(km/h)1.37/1.22Gradeability(%)30Average ground pressure(MPa)0.06Max. single line speed of tower jib luffing system(m/min)-Max. single line speed of SL luffing system(m/min)-Engine *Model-SC7H210.1G3/QSB6.7Engine power(kW)155/153Emission-National III stage/Europe IIIMass *Crane overall mass(t)46.3(Main hook,13m boom)Max. weight of single unit for transport(t)28.6
