• Model NO.：XCT35
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Straight Arm
• Overall Length：12620mm
• Overall Width：2500mm
• Overall Height：3350mm
• Total Mass in Travel State：36470kg
• Max. Travel Speed：75km,H
• Min. Ground Clearance：260mm
• Max. Grade-Ability：40%
• Max. Total Rated Lifting Capacity：35t
• Min. Rated Working Radius：3m
• Boom Raising Time：68s
• Transport Package：Seaworthy Packing
• Specification：ISO, CE
• Trademark：EON
• Origin：Xuzhou, China
• HS Code：87051091
• Production Capacity：50 Sets,Months

ItemUnitParametersDimensionsOverall lengthmm12620Overall widthmm2500Overall heightmm3350WeightDead weight in travel statekg36470AxleAxle 1,2kg12470Axle 3,4kg24000PowerEngine rated outputkw/(r/min)206/2200Engine rated torqueN.m/(r/min)1100/1400Max. Travel speedr/min2200TravelTravel speedMax. Travel speedkm/h75Turning diameterMin. tuning diametermm19500Min. ground clearancemm260Approach angle 17°Departure angle 15.7°Max. Grand ability%40%Fuel consumption of 100kmL30

Table 2-2 Main Technical Data for Lifting OperationItemUnitParametersLifting performanceMax. Total rated lifting loadt35Min. rated working radiusm3Turning radius at swing table tailm3.055Max. Load momentBase boomkN. m1200Full-extend boomkN. m674.24Outrigger extension distanceLongitudinalm5.35Lateralm6.0Working speedBoom elevating timeBoom risings68Boom telescoping timeFull-extendings155Max. Slewing speedr/min2.5
Hoisting speed
(single, the 3rd layer)


Main winchFull loadm/min75No loadm/min130Auxiliary winchFull loadm/min75No loadm/min130
