2020 Zoomlion 30 Ton Mobile Truck Crane Ztc300h552

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Certification：GS, RoHS, CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：52m
  • Maximum Lifting Weight：30ton
  • Shaft Number：3
  • Crane Jib：Five-Arm

Base Info

  • Model NO.：Ztc300H552
  • Type：Straight Arm
  • Rated Loading Capacity：30ton
  • Max. Lifting Height of Jib：52m
  • Max. Load Moment of Basic Boom：1283kn.M
  • Engine：Wp9h310e50
  • Power：228kw,1900rpm
  • Weight：34580kg
  • Transport Package：Nude
  • Specification：30ton
  • Trademark：ZOOMLION
  • Origin：Hunan China
  • HS Code：87051091
  • Production Capacity：500unit,Month

Description

Working performanceMax. rated lifting capacitykg30000Max. load moment of basic boomkN.m1283Max. lifting height of basic boomm11.2Max. lifting height of main boomm44Max. lifting height of jibm52Working  speeds              Max. hoist rope speed(Main winch)m/min140Boom demrricking up times35Boom telescoping out times80Slewing speedr/min2.7Driving parametersMax. driving  speedkm/h80Max. gradeability%45Min. Turning diameterm≤21Min.  ground clearancemm260Oil consumption per hundred kilometersL40MassDeadweight in driving conditionkg34580DimensionsOverall  dimensions(L×W×H)mm13450×2650×3550
