• Model NO.：QY800V
• Type：Folding
• Max. Load Moment of Basic Boom：2009kn.M
• Max. Hoist Rope Speed(Main Winch)：120m,Min
• Boom Demrricking up Time：50s
• Max. Driving Speed：76km,H
• Front Axle Load：16000kg
• Rear Axle Load：26000kg
• Transport Package：Nude or as Your Request
• Specification：2009kN. m
• Trademark：ZOOMLION
• Origin：China
• HS Code：8426120000
• Production Capacity：1000000pieces,Year

Working    performanceMax.    rated lifting capacitykg55000Max.    load moment of basic boomkN.m2009Max.    load moment of main boom(fully extended)kN.m1050Max.    load moment of basic boomm12.6Max.    lifting height of main boomm43.6Max.    lifting height of jibm59.5Working    speeds              Max.    hoist rope speed(Main winch)m/min120Boom    demrricking up times50Boom    demrricking up times95DrivingMax.    driving  speedkm/h76Min.  ground clearancemm260Oil    consumption per hundred kilometersL43MassDeadweight    in driving conditionkg42000Complete    vehicle kerb masskg41870Front    axle loadkg16000Rear    axle loadkg26000DimensionOverall    dimensions(L×W×H)mm13700×2800×3650Longitudinal    distance between outriggersm5.92Transversal    distance between outriggersmFully extended: 7.1,
Intermediately extended: 4.8Tail    slewing radiusmm3900Main    boom lengthm11.4 - 43.0
