12 Ton Mini Small Mobile Truck Crane (QY12K)
Evangel Industrial (Shanghai) Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Maximum Lifting Height：30-40m
- Maximum Lifting Weight：11-13t
- Shaft Number：2
- Crane Jib：Three-Arm
Base Info
- Model NO.：QY12K
- Type：Straight Arm
- Application：Construction Usage
- Transport Package：Nude
- Specification：Euro III
- Origin：Jiangsu, China
- HS Code：8426990000
- Production Capacity：30 Sets Per Month
Description
158/2200155/2200170/2200
790/1400820/1400830/1400
Engine rated torque
N.m/(r/min)
Travel
Max. travel speed
km/h
6875
Min. turning diameter
mm
18000
Min. ground clearance
mm
260
Approach angle
°
21
Departure angle
°
10
Max. grade ability
%
≥26≥28
Fuel consumption for 100km
L
30 40
Main performance
Max. rated total lifting capacity
t
12
Min. rated working radius
m
3
Turning radius at turntable tail
m
2.6
Max. lifting torque
kN.m
428
Base boom
m
9.3
Fully extended boom
m
23
Fully extended boom+jib
m
29.4
Longitudinal outrigger span
m
4.1
Lateral outrigger span
m
4.9
Working speed
Boom luffing time
s
50
Boom full extension time
s
75
Max. swing speed
r/min
2.6
Main winch full load/no load (single rope)
m/min
110
