130 Tons Truck Crane Qy130K
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Certification：GS, RoHS, CE, ISO9001, ISO9001: 2000, GOST
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
Base Info
- Model NO.：QY130K
- Shaft Number：5
- Crane Jib：Five-Arm
- Type：Straight Arm
- Color：Golden Yellow
- Power Source：Hydraulic
- Sling Type：Wire Rope
- Lifting Height：112m
- Transport Package：Standard Export Seaworthy Packaging
- Trademark：EON
- Origin：Jiangsu, China
- Production Capacity：280 Sets,Month
Description
ItemUnitParameterOutline dimensionOverall lengthmm14950Overall widthmm3000Overall heightmm3950Axle baseAxle 1, Axle 2mm1420Axle 2, Axle 3mm2420Axle 3, Axle 4mm1875Axle 4, Axle 5mm1350Axle 5, Axle 6mm1400Wheel basemm2610/2307MassTotal mass in travel statekg62000Axle loadAxle 1, Axle 2kg8800/8800Axle 3, Axle 4kg9200/12700Axle 5, Axle 6kg12700/9800PowerCrane superstructure engineRated powerkw/(r/min)162/2100Rated torqueN. m/(r/min)854/1400Rated speedr/min2100Crane carrier engineRated powerkw/(r/min)390/1800Rated torqueN. m/(r/min)2400/1080Rated speedr/min2000Travel performanceTravel speedMax. travel speedkm/h70Min. stable travel speedkm/h2.1Min. turning diameterm24Min. ground clearancemm275Approach angle(° )23Departure angle(° )14Braking distance (at 30km/h)m≤ 10Max. grade-ability%40Fuel consumption for 100kmL
