• Model NO.：LH Model
• GB/T 24001-2004 Idt ISO14001: 2004：Passed
• GB/T 19001-2000 Idt ISO 9001: 2000：Passed
• GB/T 28001-2001, OHSAS18001: 1999：Passed
• Limited Switch：Included
• Polyurethane Material Buffer：Included
• Current Overload Protection System：Included
• Voltage Lower Protection Function：Included
• Lifting Mechanism：Electrical Hoist
• Main Electrical Parts：Siemens Brand
• Painting Color：According to Your Demand
• Application：Workshop Usage, Mineral Area Usage
• Sling Type：Wire Rope
• Power Source：Electric
• Moving Type：Wheel
• Installation：Overall Rapid Disassembly
• Transport Package：Export Standard
• Specification：Chinese Standard
• Trademark：Kuangyuan
• Origin：China
• HS Code：84261120
• Production Capacity：10000sets,Year

Lifting capacity (t)5105/3.210/3.216/3.220/532/550/10Span (m)10.5-31.5
Max. Lifting

 height (m)
Main lift16121612
Aux lift
//
//
18
16
18141818Speed
m/min
Main lift


A512.6 8.5 9.3 8.5 7.85.87.86
A612.810.312.810.39.77.29.57.8
Aux. Lift  9.59.59.512.612.6(A5)
12.8(A6)8.5(A5)
10.3 (A6)Trolley Travel4044.537.243.844.644.642.438.5Motor
(kw)
Main lift
A513 17 13 17 26265255
A61522152230305575
Aux lift////7.57.57.5171722Trolley 2.52.5 2.52.2 3.73.7
5.5
7.5Work dutyA5, A6Power supply380V, 50Hz, 3-phase
