• Model NO.：Qy70V552
• Type：Folding
• Jib Length：9.5 16m
• Max. Traveling Speed：75km,H
• Minimum Turn Radius：12m
• Min. Ground Clearance：280mm
• Transport Package：Nude Package
• Specification：14100*2750*3750mm
• Trademark：XCM_G
• Origin：Jiangsu, China
• HS Code：87051091
• Production Capacity：1000units,Month

Working performance1Max. rated lifting weight × working radiuskg.m70000×3.02Max. lifting torque of basic boomkN.m23523Max.lifting torque of longest main boomkN.m10984Max. lifting height of longest main boomm44.25Max. lifting height of jibm60.2Dimensions6Outline dimensions (L×W×H)mm14100×2750×37507Distance between outriggers (longitudinal × transversal)mm6000×76008Main boom length (completely retracted - completely extended)m11.6~449Jib lengthm9.51610Main boom angle of elevation°-2~8011Swing range 360°continuouslyWorking speed12Max.speed of single rope on the drum of main winchm/min13513Boom extension times10714Boom derricking up times5715Swing speedr/min0~1.8Mass16Complete vehicle kerb masskg4487017Front axle loadkg1900018Rear axle loadkg26000Traveling19Max. traveling speedkm/h7520Max. gradeability%3721Minimum turn radiusm1222Min. ground clearancemm280
