• Model NO.：XCT100
• Type：Folding
• Max. Travel Speed：90km,H
• Wheel Base：1920+3500+1420+1505mm
• Engine Rated Torque：860,1200-1700n.M,(R,Min),1000,1200-1600n.M,(R,Min)
• Max. Total Rated Lifting Capacity：100t
• Transport Package：Nude Package
• Specification：15600X3000X3870mm
• Trademark：XCM_G
• Origin：Xuzhou
• HS Code：87051022
• Production Capacity：1000units,Month


Category
Item
UnitParameterXCT100(G1)

Outline DimensionsLength×Width×Heightmm15600×3000×3870Wheel basemm1920+3500+1420+1505Track(front/rear)mm2449/2315Front/Rear overhangmm2650/2765Front/Rear extensionmm1840/0


WeightMax. gross vehicle weightkg55000

Axle load1st Axlekg100002nd Axlekg100003rd Axlekg130004th Axlekg130005th Axlekg9000





TravelMax. travel speedkm/h90Min. turning diameterm23Min. ground clearancemm326Approach / departure angle°18/13Braking distance(initial brake speed at 30 km/h)m≤10Max. grade ability%45Exterior noise leveldB(A)≤88Noise level at seated positiondB(A)≤90 Oil consumption per 100 km L70(Weichai )65(cummins)
Chassis





EngineModel--WP6G240E330OM906LA.E3A/2Rated power/ rotating speedkW/(r/min) 176/2300 190/2200Max. output torque/rotating speed N.m/(r/min)860/1200-17001000/1200-1600Model--WP12.430 E50ISM11E5 440Rated power/ rotating speedkW/(r/min) 316/1900 324/1900Max. output torque/ rotating speed N.m/(r/min)2060/1000-1400 2080/1200
