• Model NO.：QY130K
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Truck Crane
• Lifting Capacity：130ton
• Swing Speed：1.8r,Min
• Rated Output：324kw
• Travel Speed：76km,H
• Application：Construction Usage
• Tower Crane Type：Under Slewing Cranes
• Sling Type：Wire Rope
• Main Girder Form：Single Girder
• Power Source：Electric
• Transport Package：Nude Packing
• Specification：CE ISO
• Trademark：EON
• Origin：Xuzhou Jiangsu
• HS Code：8701200000
• Production Capacity：100set,Months

CategoryItemUnitParameterMain Lifting PerformanceMax. total rated lifting capacityt130Min. rated working radiusm3Turning radius at turntable tail (counterweight)mm4600Max. load momentBase boomkN.m5003Fully-extended boomkN.m2090Outrigger spanLongitudinalm7.56Lateralm7.6(5.2)Hoist heightBase boomm13Fully-extended boomm58Fully-extended boom +28m Jibm86Boom lengthBase boomm13Fully-extended boomm58Fully-extended boom +28m Jibm86Jib offset angle°0, 15, 30Working
SpeedElevating timeBoom raisings60Telescoping timeFully extendeds420Fully retracteds400Max. swing speedr/min1.8Outrigger extending and retracting timeOutrigger
beamExtending
Simultaneouslys50Retracting
Simultaneouslys40Outrigger
jackExtending
Simultaneouslys50Retracting
Simultaneouslys45Hoist speed (single line, 4th layer)Main winchNo loadm/min115Auxiliary winchNo loadm/min115NoiseExterior noise leveldB (A)≤118Noise level at seated positiondB (A)≤90
