• Model NO.：STC250
• Type：Truck Crane
• Rated Lifting Moment：5003 Kn.M
• Max. Lifting Load：110ton
• Max. Lifting Height：86m
• Application：Construction Usage
• Tower Crane Type：Under Slewing Cranes
• Sling Type：Wire Rope
• Main Girder Form：Single Girder
• Power Source：Electric
• Moving Type：Wheel
• Installation：Assembled
• Transport Package：Nude Packing
• Specification：CE ISO
• Origin：Hunan
• Production Capacity：100set,Months

Max rated lifting capacity25tOverall length12750mmOverall width2500mmOverall height3550mm Dimensions and Weights Overall length12750 mm Overall width2500 mmOverall height3550 mmAxle distance Axle 1-2
Axle 2-34325 mm
1350 mm Overall weight30000 kgAxle load Axle load 1-2
Axle load 3-46500 kg
23500 kgCrane Carrier Engine model
 DongFeng Cummins
ISLe 290 30Rated power
 290/213/2100
hp/kw/rpmRated torque
 1050 Nm/
1200-1400 rpmMax. travelling speed 80 km/h Min. turning radius11000 mmMin. turning radius of boom head 12650 mmWheel formula6×4Wheel dimension11.00R20 Spare wheelincludedMin. ground clearance220 mmApproach angle17°Departure angle12°Max. gradeability38 %Fuel reservoir300 lFuel consumption per 100 km≤37 lWorking fuel consumption per hour10 l/hStandard toolboxincludedFire extinguisherincludedHeating system in lower and upper cabincludedCrane Superstructure Temperature range-25° till +40°   Min. rated range3 mTail slewing radius of swingtable3370 mm Boom section4Boom shapeU-shapeMax. lifting moment  Base boom
Full-extended boom
Full-extended boom+jib98.2 t.m
55.5 t.m
37.7 t.mBoom length  Base boom
Full-extended boom
Full-extended boom+jib10.65 m
33.5 m
41.5 mOutrigger span (Longitudinal x Transversal)6200 x 5300 mm Jib offset0° 15° 30°Max. single rope lifting speed of main winch (no load)125 m/minMax. single rope lifting speed of auxiliary winch (no load)125 m/minFull extension/retraction time to boom95/60 sFull lifting/descending time to boom45/60 sSlewing speed2.2 r/minHigh Voltage Detectornot includedOptions Arctic Package for temperature range till -40°C Air conditioning for lower and upper cab
The key vehicle features:
Lifting capacity: 25 t
Boom length: 10.6 - 33.5 m, 4 sections
Intensive Quality Control - Quality inspections done by PALFINGER specialists before shipment
Reliable Service - Warranty term: 2250 working hours or 18 months
Efficiency - Optimized lifting performance cost ratio
Documentation and Crane Control Software available in English and Russian language
(other languages on request)
Usability - Simple to operate and maintain
