Zoomlion 50ton Truck Crane Qy50V532 with 5 Section Telescopic Boom
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Type：Single Girder Crane
- Max. Rated Lifting Weight：50ton
- Max. Lifting Height of Basic Boom：11.1m
- Max. Lifting Height of Fly Jib：58.3m
Base Info
- Model NO.：QY50V532
- Outline Dimensions：13300×2750×3650mm
- Max. Traveling Speed：76km,H
- Boom Extension Time：95s
- Tower Crane Type：Slewing Tower Crane
- Sling Type：Wire Rope
- Main Girder Form：Single Girder
- Transport Package：Nude Packing
- Specification：CE, ISO9001
- Trademark：ZOOMLION
- Origin：Jiangsu, China
- HS Code：87051092
- Production Capacity：100 Set,Sets , Month
Description
Working performance1 Max. rated lifting weight × working radius kg.m 50000×3.0 2 Max. lifting torque of basic boom kN.m 1764 3 Max. lifting torque of longest main boom kN.m 940.8 4 Max. lifting height of longest main boom m 42.1 5 Max. lifting height of jib m 58.3 Dimensions 6 Outline dimensions (L×W×H) mm 13300×2750×3650 7 Distance between outriggers (longitudinal × transversal) mm 5920×6900 8 Main boom length (completely retracted - completely extended) m 11.1~42 9 Jib length m 9.516 10 Main boom angle of elevation ° -2~80 11 Swing range 360°continuously Working speed 12 Max.speed of single rope on the drum of main winch m/min 130 13 Boom extension time s 95 14 Boom derricking up time s 50 15 Swing speed r/min 0~2 Mass 16 Complete vehicle kerb mass kg 40870 17 Front axle load kg 15000 18 Rear axle load kg 26000 Traveling 19 Max. traveling speed km/h 76 20 Max. gradeability % 40 21 Min. turn radius m 12 22 Min. ground clearance mm 280
