Zoomlion 50ton Rhd Mobile Truck Crane Zrt500r532
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Spare Parts Free
- Warranty：1 Year
- Certification：GS, RoHS, CE, ISO9001, ISO9001: 2000
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
Base Info
- Model NO.：ZRT600R532
- Shaft Number：2
- Crane Jib：Four-Arm
- Type：Small Crane
- Rated Loading Capacity：55ton
- Engine：Weichai Engine
- Optional：Left Hand Drive
- Transport Package：Suitable Package for Shipment
- Specification：ISO
- Trademark：Zoomlion
- Origin：Changsha, China
- HS Code：87051091
- Production Capacity：30 Sets,Month
Description
Item
Value
Remarks
Working performance
Max. rated lifting capacity kg
55000
Max. load moment of basic boom kN.m
2009
Max. load moment of Max. length main boom kN.m
1050
Max. lifting height of basic boom m
12.6
Max. lifting height of main boom m
43.6
These parameters do not include deflection of boom and jib.
Max. lifting height of jib m
59.5
Working
speeds
Max. hoist rope speed (Main winch) m/min
120
Max. hoist rope speed (Auxiliary winch) m/min
120
Boom derricking up time s
50
Boom telescoping out time s
95
Slewing speed r/min
0 - 2.2
Driving
Max. driving speed km/h
76
Max. gradeability %
40
Min. turning diameter m
≤24
Min. ground clearance mm
260
Oil consumption per hundred kilometer L
43
Weight
Deadweight in driving condition kg
42000
Complete vehicle kerb mass kg
41870
Front axle load kg
16000
Rear axle load kg
26000
Dimension
Overall dimensions (L×W×H) mm
13700X2800X3650
Longitudinal distance between outriggers m
5.92
Transversal distance between outriggers m
Completely extended:7.10m, intermediately extended:4.80m
Tail slewing radius mm
3900
Main boom length m
11.4 - 43.0
Main boom angle °
-2 - 80
Jib length m
9.5, 16.0
Offset °
0, 30
