• Model NO.：xct12l4
• Brand：XCMG
• Hydraulic Cylinder Brand：Undetermined
• Rated Loading Capacity：12 Tons
• Crane Type：Telescopic Straight Boom Crane
• Feature：Truck Crane
• Applicable Industries：Manufacturing Plant, Farms, Construction Works
• After-Sales Service Provided：Field Installation, Commissioning and Training
• Hydraulic Valve Brand：Undetermined
• Application：Construction
• Hydraulic Pump Brand：Undetermined
• Max. Lifting Height：31.1m
• Capacity：8-15 Ton Truck Crane
• Transport Package：Comply with Export Packaging Requirements
• Trademark：XCMG
• Origin：Jiangsu, China, 100% China
• Production Capacity：1000 Unit,Units Per Year

Category

Item

Unit

Parameter

Max. total rated lifting capacity

t

12

Min. rated working radius

m

3

Turning radius at turntable tail

Counterweight

mm

2570

Auxiliary winch

mm

2910

Max. load moment

Base boom

t.m

48.25

Fully-extended boom

t.m

27.60

Outrigger span (fully- extended)

Longitudinal

m

4.57

Lateral

m

5.5

Base boom

m

9.5

Fully-extended boom

m

30.9

Fully-extended boom + Jib

m

38.1

Base boom

m

9.45

Fully-extended boom

m

30.5

Fully-extended boom + Jib

m

30.5+7

Jib offset angle

°

0

Boom raising

s

≤38

Telescoping time

Fully extended

s

≤58

Max. slewing speed

r/min

3

Outrigger extending and retracting time

Outrigger beam

Extending Simultaneously

s

≤20

Retracting Simultaneously

s

≤15

Outrigger jack

Extending Simultaneously

s

≤25

Retracting Simultaneously

s

≤20

Hoisting speed (single line, 4th layer)

Main winch

m/min

138

Auxiliary winch

m/min

138

Noise

Exterior noise level

dB

(A)

≤122

Noise level at seated position

dB

(A)

≤90
