• Model NO.：QY16D
• Type：Small Crane
• Rated Loading Capacity：16ton
• Engine Model：D6114zlq5b
• Engine Output：158kw
• Dimension：11990*2500*3350mm
• Power Source：Hydraulic
• Sling Type：Chain
• Transport Package：Nude, Suitable for Shiping
• Specification：Standare
• Origin：Jiangsu, China
• Production Capacity：100 Sets,Month

ItemUnitParameterEngineModel
 D6114ZLQ5BOutline dimensionOverall lengthmm11990Overall widthmm≤2500Overall heightmm3350Wheel baseAxle 1, Axle 2mm4025Axle 2, Axle 3mm1350MassTotal mass in travel statekg24000Axle loadAxle 1kg6400Axle 2kg17600Travel performanceTravel speedMax. travel speedkm/h≥70Min. stable travel speedkm/h3~4Turning diameterMin. turning diameterm≤20Min. turning diameter at boom tipm≤23Min. ground clearancemm270Approach angle(°)21Departure angle(°)10Braking distance (at 30km/h with full load)m9.5Max. grade-ability%24Fuel consumption for 100kmL35
 ItemUnitParameterLifting performanceMax. total rated lifting capacityt16Min. rated working radiusm3Turning radius at turntable tailm≤3.12Max. load momentBase boomkN.m686Fully extended boomkN.m388Fully extended boom + JibkN.m254Outrigger spanLongitudinalm4.6Lateralm5.4Lifting heightBase boomm≥9.9Fully extended boomm≥30.7Fully extended boom + Jibm≥38.5Working speedBoom raising times≤60Boom full extension times≤95Max. swing speedr/min≥2.5Hoist speed
(single line)Main winchFull loadm/min≥54No loadm/min≥100Aux. winchFull loadm/min≥54No loadm/min≥100Noise limitCrane exterior noisedB (A)≤118At seated positiondB (A)≤90
