Item | Unit | Value | | | Remarks |
---|
Maximum lifting capacity × radius | t × m | 260 × 5 | |
Deadweight of crane with basic boom | t | 210 | |
Length of main boom | S-boom length | m | 20-83 | |
SL-boom length | m | 86-95 | |
F-jib length | m | 12-30 | |
Max.lifting capacity on fixed jib | t | 34 | |
F-jib angle | . | 10,30 | |
Max. length of heavy duty boom with fixed jib | m | 77+30 | |
W-jib Length | m | 21-60 | |
Max. lifting capacity on luffing jib | t | 73.5 | |
S-boom angle( for SW boom configuration) | . | 65-85 | |
Max. length of heavy duty boom with luffing jib | m | 62+60 | |
Single rope speed of winches | Hoisting winch 1 | m/min | 130 | on the 6th rope layer |
Hosting winch 2 | m/min | 120 | Main boom derricking winch | m/min | 80Slewing speed | rpm | 0-1.2 | |
Traveling speed | km/h | 0-1.0 | |
Max.gradeability | % | 30 | |
Ground pressure | MPa | 0.115 | |
Transport weight of max.single unit | t | 32 | Excluding hoisting winches,titling-back support of main boom.A-frame and derricking mechanism |
Rear counterweight | t | 83.7 | |
Central counteweight | t | 32 | |
Engine | Manufacturer | | US Cummins | |
Rated power/rotational speed | Kw/rpm | 227/2000 | |
Max. output torque/rotational speed | Nm/rpm | 1505/1400 | |
Emission standard | | U.S.EPA Tier 3 and EU Stage III A | |
