• Model NO.：ZTC800H7
• Type：Folding
• Max. Rated Lifting Capacity：25000kg
• Max. Lifting Height of Jib：46.58m
• Max. Load Moment of Basic Boom：12.2m
• Max. Lifting Height of Main Boom：44.2m
• Transport Package：Comply with Export Packaging Requirements for Min
• Specification：12700*2500*3450 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：84262000
• Production Capacity：100 Units Per Month

Item

Unit

Value

Remarks

Working performance

Max. rated lifting capacity

kg

80000

Max. load moment of basic boom

kN.m

2575

Max. load moment of main boom(fully extended)

kN.m

1240

Max. load moment of basic boom

m

12.2

Max. lifting height of main boom

m

44.2

These parameters do not include deflection of main boom and jib

Max. lifting height of jib

m

60.2

Working speeds

Max. hoist rope speed(Main winch)

m/min

≥135

Drum 4th layer

Max. hoist rope speed(Auxiliary winch)

m/min

≥110

Drum 2th layer

Boom demrricking up time

s

57

Boom demrricking up time

s

107

Slewing  speed

r/min

1.8

Driving

Max. driving  speed

km/h

75

Max. gradeability

%

37

Turning diameter

m

24

Min.  ground clearance

mm

280

Oil consumption per hundred kilometers

L

46

Mass

Deadweight in driving condition

kg

45000

Complete vehicle kerb mass

kg

44870

Front axle load

kg

19000

Rear axle load

kg

26000

Dimension

Overall dimensions(L×W×H)

mm

14100×2750×3750

Longitudinal distance between outriggers

m

6.00

Transversal distance between outriggers

m

For completely extended outriggers: 7.60 m;
   For intermediately extended outriggers: 5.04 m

Tail slewing radius

mm

4020

Main boom length

m

11.6 - 44.0

Main boom angle

°

-2 - 80

jib length

m

9.5,16.0

Offset

°

0,30
