• Model NO.：ZTC1100V753
• Type：Folding
• Max. Rated Lifting Capacity：25000kg
• Max. Lifting Height of Jib：46.58m
• Transport Package：Comply with Export Packaging Requirements for Min
• Specification：12700*2500*3450 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：84262000
• Production Capacity：100 Units Per Month

ItemValueRemarksWork
performanceMax. rated lifting capacity     kg110000 Max. load moment of basic boom
kN.m4400At 5.5 m radiusMax. load moment of main boom (completely extended)     kN.m1880 Max. lifting height of main boom
m58.5The parameters do not include deflection of main boom and jib. The value in the brackets is for the extension installed.Max. lifting height of jib       m77 / (85)Work speedsMax. hoist rope speed (Main winch)                  m/min115At the 5^th layerMax. hoist rope speed (Auxiliary winch)                  m/min70At the 3^rd layerBoom extending time         s≥ 600It is the theoretical value with the Max. engine RPM.Boom dericking up time      s≥ 80 Slewing speed            r/min≤ 1.5 DrivingMax. driving speed        km/h78 Max. gradeability            %40 Min. turning diameter        m23 Min. ground clearance      mm280 Limits for exhaust pollutants and smokeConform to related standardsGB3847-2005
GB17691-2005
(National stage III)Oil consumption per hundred kilometers                  L75 MassDeadweight in driving condition
kg54900 Complete vehicle kerb mass  kg54705 Front axle load              kg19900 Rear axle load              kg35000 DimensionsOverall dimensions (L × W × H)
mm14690 × 3000 × 3940 Outrigger spread (L)         m7.67 Outrigger spread (W)        m7.8 m (Completely extended), 5.3 m (Intermediately extended) Main boom length           m12.8 - 57.5 Boom angle                °-1.5 - 82 Jib length                  m11, 18.6 Jib + extension length       m26.6 Offset                      °0, 30
