Zoomlion 100 Ton Rough Terrain Crane Rt100

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：Field Installation, Commissioning and Training
  • Warranty：One Year
  • Certification：GS, RoHS, CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：>40m
  • Maximum Lifting Weight：>16t

Base Info

  • Model NO.：RT100
  • Shaft Number：3
  • Crane Jib：Four-Arm
  • Type：Straight Arm
  • Transport Package：Roro,Container
  • Specification：Max Lifting Capacity: 30 t
  • Trademark：sany
  • Origin：China
  • HS Code：87051091
  • Production Capacity：500,Month

Description

ItemUnit Work performanceMax. rated lift capacity × work radiuskg.m100000×3.0Max. load moment of basic boomkN.m3339Max. load moment of fully extended main boomkN.m1388Max. lift height of fully extended main boomm45.6Max. lift height of jibm63DimensionsOverall dimensions(L×W×H)mm14247×3620×3960Outrigger spread (L×W)mm8000×7900Main boom length (Fully retracted fully extended)mm10800-34000Jib length (Jib section 1,jib sections 1+2)mm10000-17000Boom angle°-3 - 78Swing range°360       360° unlimited swing(Full range)Work SpeedsMax. hoist rope speed (Main winch)m/min126Min. boom extend times170Min. boom retract times158Min. boom derrick up times82Min. boom derrick down times69Swing speedr/min0-1.5Hydraulic systemRated work pressureMPa30Rated work oil flowL/min500Hydraulic oil tank capacityL1200MassComplete vehicle masskg65000Front axle loadkg33200Rear axle loadkg31800TravelMax. travel speed (Forwarsd / backwards)km/h24/15Wheelbasemm4600Treads (Front / rear)mm2860
