• Model NO.：Src400c
• Type：Folding
• Transport Package：Nude Package
• Origin：China
• HS Code：87051091
• Production Capacity：5000pices,Year

Basic Info.

Model NO. Src400c Type Folding Transport Package Nude Package Origin China HS Code 87051091 Production Capacity 5000pices/Year

Product Description

High Quality 40ton New Hydraulic Rough Terrain Crane Src400c

contact
Nora Li
Mobile/ :+86-17363975813

Product description

The full extension length of the main boom is 31.5 m, and the height from the ground is 33.9 m, showing a leading position in the industry; The maximum load moment of basic boom is 1175 kN.m, and that of the full extension boom is 755 kN.m, showing strong loading capacity; With four U-type main booms, and single cylinder and rope extension mechanism, it is stable and efficient; With the installation angle for jibs as 0°, 15° and 30°, it is convenient for condition switching and provides high operation efficiency.
Mobile and flexible carrier

With four-wheel drive, the maximum traveling speed is 37 km/h, and the maximum gradient is 105%(at stall), showing excellent dynamic performance. With 4 steering modes such as front wheel steering, rear wheel steering, four wheel steering and crab steering, it is good in maneuvering characteristics. Efficient and energy-saving system Load feedback, constant-power control piston pump and electric proportional control multi-valve system ensure the control precision and energy efficiency. The dual-pump converging/dividing technology achieves the composite brake cylinder, ensuring the smooth operation and efficient inching.

Safe control system

With independently researched and developed SYMC controller and CAN busbar technology, signals are stable. With intelligent protection toque limiter with the accuracy within 0-10%, suspending and loading operation is protected omnidirectionally. With comprehensive logic and interlock control and cutting off dangerous action automatically, safe and reliable operation is realized.

Comfortable manipulation experience

With integrated intelligent control busbar instrument, drivers can grasp running and driving parameters at ease. With spacious ladder stand and barrier-free table, etc., maintenance and use are easy. With electric control handle, panoramic glass sunroof, adjustable seats and other humanization design, it is relaxing and comfortable for operation.


Capacity
Max. lifting capacity	40t
Dimensions
Overall length	12200mm
Overall width	2625mm
Overall height	3575mm
Axle distance	3720mm
Weight
Overall weight	30900kg
Front axle load	15300kg
Rear axle load	15600kg
Engine
Model	Cummins
Rated power	119 kw/2500rpm
Rated torque	730N.m/1500rpm
Emission standard	EU Stage 3 A standard
Traveling
Max. traveling speed	37km/h
Min.turning radius	12.2/6.2m
Approach angle	23.3°
Departure angle	23.1°
Max. gradeability	105%(at stall)
Main Performance
Temperature range	-20°-46°
Boom section	4
Boom shape	U-shaped
Max. lifting moment-Base boom	1175kN.m
Max. lifting moment-Full-extend boom	755kN.m
Length-Base boom	10m
Length-Full-extend boom	31.5m
Length-Full-extend boom+jib	45.2m
Outrigger span(Longitudinal/Transversal)	6.15/6.15m
Jib offset	0°15°30°
Working Speed
Max. single rope lifting speed of main winch(no load)	130m/min
Max. single rope lifting speed of auxiliary winch(no load)	130m/min
Full extend/retract time of boom	36/43s
Full raise/lower time of boom	50/60s
Swing speed	2.8r/min
