85 Ton Xct85 Heavy Duty Hydraulic Machinery Truck Crane for Construction
Shanghai Super-Above Industry Holdings Co., Ltd.- Condition：New
- Maximum Lifting Height：65m
Base Info
- Model NO.：XCT85
- Maximum Lifting Weight：85000kgs
- Shaft Number：4
- Crane Jib：Five-Arm
- Type：Telescopic
- Max Lifting Capacity：85ton
- Rated Power：297kw
- Total Weight：47805 Kg
- Length：14960mm
- Width：2750mm
- Height：3960mm
- Speed：80km,H
- Cabin：Full Cabin
- A/C：Yes
- Emission：Euro III
- Warranty：1 Year
- Aftersales Service：Oversea Service, Free Spare Parts, etc
- Control System：Pilot Control
- Certificate：ISO CCC
- Transport Package：Roro Ship , Bulk Ship
- Specification：Mobile crane
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8705109100
- Production Capacity：10000units,Year
Description
Axle base1st ,2nd axlemm14702nd ,3rd axle40003rd ,4th axle1350Wheel Base mm 2380+2075Total vehicle mass in travel configuration kg47805Axle load 1st and 2nd Axlekg240003rd and 4th Axle26000Engine Model WP12.375N/MC11.39-30Engine rated power kw/(r/min)276-290/1900Engine rated torque N.m/(r/min)1800-1900/1000-1400Max. travel speed km/h80Min. steady travel speed km/h3Min. turning diameter m24Min. turning diameter at boom tip m29Min. ground clearance mm371Max. grade ability %40Approach angle °17Departure angle °15.5Braking distance (at 30 km/h, full load ) m≤10Oil consumption per 100km L45
