• Model NO.：XCT75
• Maximum Lifting Weight：75000kgs
• Shaft Number：4
• Crane Jib：Five-Arm
• Type：Telescopic
• Max Lifting Capacity：75ton
• Rated Power：268kw
• Total Weight：43000 Kg
• Length：14700mm
• Width：2750mm
• Height：3910mm
• Speed：90km,H
• Cabin：Full Cabin
• A/C：Yes
• Emission：Euro III
• Warranty：1 Year
• Aftersales Service：Oversea Service, Free Spare Parts, etc
• Control System：Pilot Control
• Certificate：ISO CCC
• Transport Package：Roro Ship , Bulk Ship
• Specification：Mobile crane
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000units,Year

ItemParameterUnitMax. total rated lifting capacity75tMin. rated working radius3mTurning radius at turntable tailCounterweight4350mmAuxiliary winch4545mmBase boom3175kN.mFully-extended boom1615kN.mMax. load momentFully-extended boom + Jib1011kN.mThe longest boom + jib (optinal insert)647kN.mOutrigger span (fully-extended)Longitudinal8.45mBase boom12.7mFully-extended boom48mHoist heightFully-extended boom + Jib65.0/74(optional)mThe longest boom + jib (optinal insert)74.5kN.mBase boom12.4m
