100 Ton Crawler Crane Xgc100 Factory Original
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Application：Workshop, Warehouse, Coal Stack, Port, Wharf
- Anchor：Removable
- Structure：Solid Web
- Material：Wood
Base Info
- Model NO.：XGC100
- Type：Herringbone
- Max. Lifting Capacity：100ton
- Dimension：9.6*3.3*3.3m
- Engine Output：184kw
- Weight for Transport：40kg
- Max. Load Moment：5395kn.M
- Brand：Oriemac
- Color：Yellow
- Rated Loading Capacity：100t
- Weight：50t
- Hooks：3
- Transport Package：Nude
- Specification：ISO, CCC
- Trademark：ORIEMAC
- Origin：Jiangsu, China
- HS Code：84264910
- Production Capacity：4000PCS,Month
Description
Item
Unit
Parameter
Max. lifting capacity
Boom
t
100
Jib
t
11
Max. load moment
kN.m
5395
Boom length
m
18 ~ 72
Boom elevating angle
°
0 ~ 80°
Fixed jib length
m
12 ~ 24
Fixed jib offset
10° , 30°
Max. single line hoist speed (at 5th layer with no load)
m/min
100
Max. single line elevating speed (at 5th layer with no load)
m/min
45
Max. swing speed
r/min
1.4
Travel speed
km/h
1.1
Min. elevating time
s
240
Winch hoist speed(with full load)
m/min
4
Max. grade-ability
30%
Mean ground pressure
MPa
0.0927
M11-C250 Engine output
kW
184
Total mass (main hook block,18m boom)
t
114
Max. base machine weight for transport
(without counterweight, L/R crawler, lattice boom)
t
40.0
Max. base machine dimension for transport (L×W×H)
m
9.6×3.3×3.3
