Cheap 100 Ton Hydraulic Crawler Crane Quy100
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification:GS, RoHS, CE, ISO9001
- Condition:New
- Maximum Lifting Height:>40m
- Maximum Lifting Weight:>16t
- Shaft Number:3
- Crane Jib:Five-Arm
Base Info
- Model NO.:QUY100
- Type:Folding
- Max. Lifting Capacity:100ton
- Dimension:9.6*3.3*3.3m
- Engine Output:184kw
- Weight for Transport:40kg
- Max. Load Moment:5395kn.M
- Transport Package:Nude
- Specification:ISO, CCC
- Trademark:Oriemac
- Origin:Jiangsu, China
- HS Code:84264910
- Production Capacity:300sets,Month
Description
Item
Unit
Parameter
Max. lifting capacity
Boom
t
100
Jib
t
11
Max. load moment
kN.m
5395
Boom length
m
18 ~ 72
Boom elevating angle
°
0 ~ 80°
Fixed jib length
m
12 ~ 24
Fixed jib offset
10° , 30°
Max. single line hoist speed (at 5th layer with no load)
m/min
100
Max. single line elevating speed (at 5th layer with no load)
m/min
45
Max. swing speed
r/min
1.4
Travel speed
km/h
1.1
Min. elevating time
s
240
Winch hoist speed(with full load)
m/min
4
Max. grade-ability
30%
Mean ground pressure
MPa
0.0927
M11-C250 Engine output
kW
184
Total mass (main hook block,18m boom)
t
114
Max. base machine weight for transport
(without counterweight, L/R crawler, lattice boom)
t
40.0
Max. base machine dimension for transport (L×W×H)
m
9.6×3.3×3.3
100 ton crawler crane 100 ton (QUY100)
Specifications
100 ton crawler crane QUY100
1. Competitive price;
2. Good after sales service;
3. Quick delivery;
4. Small order is acceptable
100 ton crawler crane 100 ton (QUY100)
Specifications
100 ton crawler crane QUY100
1. Competitive price;
2. Good after sales service;
3. Quick delivery;
4. Small order is acceptable
