Electric Hoist Overhead Crane Gantry Crane Hoist
Henan Kuangshan Crane Co., Ltd.- Certification：CE, ISO9001: 2000
- Condition：New
- Operation Form：Ground Operation
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：<20t
- Weight Overload Protection Device：Include
Base Info
- Model NO.：CD, MD
- Voltage Lower Protection Function：Include
- Sandblast：Could Supply
- Painting Color：According to Your Demand
- Industrial Voltage：According to Your Demand
- Electric Hoist Double Limit：Include
- Sling Type：Wire Rope
- Power Source：Electric
- Moving Type：Car Type
- Installation：Jack-up
- Transport Package：Packed by Plywood Crate All by Export Standard
- Specification：China National standard
- Trademark：KUANGYUAN
- Origin：Xinxiang, Henan Province
- HS Code：84251100
- Production Capacity：28, 000 Sets,Year
Description
ModelCD1 MD1 Capacity Tons 0.25 0.5 1 2 3 5 10 16 Hoisting height M 3, 6, 9 6, 9, 12 6, 9, 12, 18, 24, 30 9, 12, 18, 24, 30 Hoisting speed M/MIN 8(0.8/8) 8(0.8/8) 8(0.8/8) 7(0.7/7) 3.5 (0.35/3.5) Travel speed M/MIN 20 20/30 20/30 20/30 20/30 20/30 20/30 18 Wirerope Dia. (mm) 3.6 4.8 7.4 11 13 15 15 17.5 Spec. 6x39 6x37+FC 6x37+FC 6x37+FC 6x37+FC Hoisting motor Type Type ZD112-4 ZD121-4 ZD122-4 ZD131-4 ZD132-4 ZD141-4 ZD151-4 ZD151-4 ZDS1 0.2/0.8 ZDS1 0.2/1.5 ZDS1 0.4/3.0 ZDS1 0.4/4.5 ZDS1 0.8/7.5 ZDS1 1.5/13 ZDS1 1.5/13 Power Power(kW) 0.4 0.8(0.2/0.8) 1.5(0.2/1.5) 3.0(0.4/3.0) 4.5(0.4/4.5) 7.5(0.8/7.5) 13(1.5/13) 13(1.5/13) Rotation speed Rotation speed(r/min) 1380 1380 1380 1380 1380 1400 1400 1400 Current (A) 1.25 2.2(0.72/2.4) 4.3(0.72/4.3) 7.6(1.25/7.6) 11(2.4/11) 18(2.4/18) 30(5.2/30) 30(5.2/30) Travel motor Type Type ZDY110-4 ZDY111-4 ZDY111-4 ZDY112-4 ZDY112-4 ZDY121-4 ZDY121-4 ZDY121-4 Power Power(kW) 0.06 0.2 0.2 0.4 0.4 0.8 0.8x2 0.8x2 Rotation speed Rotation speed(r/min) 1400 1380 1380 1380 1380 1380 1380 1380 Current Current(A) 0.3 0.72 0.72 1.25 1.25 2.4 2.4 2.4 Power AC 380V, 50HZ, 3P(As your demand)
1. High durability
2. Low maintenance cost
3. Hassle free operation
4. Easy handling
5. Long working life
Main use
The hoist installed on many kinds of cranes of suspending from T-steel can lift heavy objects straight or in a curve. The stationary ones installed on fixed trestle can lift objects vertically or from different angles.
The products are widely used at industrial ore enterprises, railway, harbors, warehouses and materials sites etc. They are indispensable machinery to improve working conditions and efficiency in manufacturing.
Applicable scope and working conditions
The product applies to such an environment as no faire, no explosive danger, no corrosive media and no dirt exist. And the temperature is between 20° C below zero and 40° C up zero, the wetness is no higher than 85%, the applicable power source is 3_phase alternating current (A. C for short), 50 Hz (60Hz) frequency and (380V~66V) voltage. Their rated load must be reduced by 20%accordingly as their working grade increases by one grade compared to their middle-lever working grade.
Safety features:
Overload protection, Main lifting motor with thermal protection, Hooks with latch, Rubber buffers
Protective earthing, Crane switch and travel end switch, Emergency switch.
Sub-assemblies characteristic are tested before assembly.
All cranes must be pre-assembled and tested before leaving factory and offer the certification of test.
Design and construction rules:
All the standards which is required for the crane is the Chinese standard
Painting:
Primer and finishing paint
Average thickness: About 100 microns.
Color: According to your demand.
Our company manufactures electric hoists with different capacity as your specific drawing. Feel free to contact with us for the detailed specification if you are interested in, each products can be designed and manufactured as your local actual condition. We continue improving on design, techniques, and method of inspection on various projects.
