Oriemac 10ton Spt1009 Lifting Capacity Big Crawler Spider Crane with CE
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Max. Lifting Height：12.9m
- Rated Loading Capacity：10ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
- Model：Spt1009 Spider Crawler Crane
Base Info
- Model NO.：SPT1009
- Lifting Capacity：10.0t*2.5m
- Maximum Radius：19m*0.50t
- Max.Lifting Height：20.2m*3.0t
- Max.Lifting Depth：20-125m
- Hook up Speed：12-18m,Min
- Crane Arm Length：6.0m-19.6m
- Walking Speed：0-3.2km , H
- Vehicle Weight：11500kg
- Transport Package：Wooden Case or Nude Package
- Specification：6380*1780*2610mm
- Trademark：ORIEMAC
- Origin：China
- HS Code：8426491000
- Production Capacity：100 Units,Month
Description
Model
SPT1009
Capacity
10.0t×2.5m
Working radius
19m×0.50t
Ground lifting height
20.2mx3.0t
Underground lifting height
20m-6 fall 30m-4 fall
62m-2 fall 125m-1 fall
Winch device
Hook speed
0-12m/min (6 fall) 0-18m/min (4 fall)
Rope type
Φ10mm×150m
Telescopic system
Boom form
5 section boom, hexagonal box construction
Boom length/Time
6.0m-19.6m/55sec
Up and downs
Boom angle/Time
0-80°/25sec
Slew system
Slew angle/Speed
0-360°(continuous)/60sec
Outrigger
Outrigger active form
Manual + Hydraulic
Maximum extended dimensions (mm)
6850(Length)X7100(Front)X6970(Back)
Traction system
Walking way
Hydraulic motor drive,2 speed
Walking speed
0-2.5km/ h
Grade ability
23°(42%)
Ground length×width
2235mm×400 mm
Ground pressure
67kpa(0.68 kgf/cm²)
Electric motor
Voltage
AC380V(Optional)
Power/Speed
15kw/1440 min-1
Sound level
Rated speed ≤78dB(A) (1m)
Diesel engine
Model
4TNV88C (YANMAR)
Type/Displacement
4 Cylinder water cooled/2.19L
Rated output
29.1kw/2400 min-1
Starting method
Electric
Operating temperature
-5°C~40°C
Fuel/Volume
Diesel/60L
Battery capacity
12v 60AH
Specific fuel consumption
239g/kW-h
Sound Level
Rated speed ≤92dB(A) (1m)
Applied regulation/Altitude
EPA-Tier4,EC stage V/1200m
Operate system
Type of operation
Diesel engine, Electric motor, Radio remote control, Searcher hook, Black rubber track, Intelligent display screen, Moment limiter, Over hoist alarm and automatic stop device, Three-winding alarm and automatic stop device, Automatic hook stow, Outrigger position detector device, Outrigger off the ground alarm and automatic stop device, Slinging rope detachment protector, EMO switch, Three color lamp, Remote control lamp, Voice prompt, Walking/Outrigger/Boom three-mode interlock system, Data records
Optional configuration
Glass suction, White rubber track, Manual fly jib, Hydraulic fly jib, Single-man basket, Outrigger pads
