• Model NO.：ZCC550H-1
• Max Lifting Moment：209 T×m
• Maximum Lifting Weight of Fixed Sub-Arm：12m
• Transport Package：Nude Package
• Specification：3000× 4600(3300)× 3120
• Trademark：Evangel
• Origin：China
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. ZCC550H-1 Max Lifting Moment 209 T×m Maximum Lifting Weight of Fixed Sub-Arm 12m Transport Package Nude Package Specification 3000× 4600(3300)× 3120 Trademark Evangel Origin China Production Capacity 100 Sets/Month

Product Description

1. Strong lifting capacity:
The large-gauge tracked chassis guarantees excellent overall machine stability within a 360° rotation range. The maximum lifting torque is 209t•m, and the maximum lifting capacity under fixed jib conditions is 12t.
The maximum length of the main boom is 52m, and the maximum length of the main boom + fixed jib is 43m+15m.
2. Good versatility of parts:
In addition to most electrical and hydraulic components on the same platform, most of the structural parts are also interchangeable, such as fixed jibs, goose head frames, hooks, luffing mechanisms, counterweight bases, etc., which greatly reduces purchase and maintenance costs .
2. Comprehensive safety protection:
Standard configuration torque limiter, lifting height limiter, main boom angle limiter, wire rope over-discharge protection device, luffing ratchet locking mechanism, anti-backward device, anemometer, aviation warning light, three-color warning light , A series of safety devices such as the hydraulic system overflow valve to ensure the safety of the whole machine.
3. Strong suitability of working conditions:
Tandem multi-channel valve-controlled hydraulic system, all actions can be combined, and switching between actions does not slow down.
The free-falling hook hoist is optional to meet most of the foundation construction requirements.
One button can realize the switching of main and auxiliary hook working conditions, which is more convenient.
4. Optimization of transportation and disassembly:
The herringbone can be lifted up without the need of an oil cylinder to realize quick assembly;
The weight of a single counterweight does not exceed 6.25t, and the small auxiliary lifting equipment can complete the counterweight assembly;
The crawler is retractable, and the maximum transportation width of the whole machine is 3.12m.

Model No.	ZC550H-1
Outline dimension	13000×4600(3300)×3120mm
Total weight in travel	55000kg
The arm length	13~52
Slewing Speed	26000kg
Maximum lifting capacity of fixed jib	12t
Main boom length	13-52
Fixed jib length	7-15m
Weight of the whole machine	49.2tons
Engine Model	WP6G190E301
