• Model NO.：QY25K5-I
• Type：Straight Arm
• Engine Rated Torque：1112,1400n.M,(R,Min)
• Span：3m
• Max. Grade Ability：40%
• Max. Travel Speed：80km,H
• Transport Package：Roro or Bullk Shipment
• Specification：13930*2780*3630mm
• Origin：Jiangsu, China
• Production Capacity：50 Sets,Month

DescriptionUnitParameter valueOverall lengthmm12300Overall widthmm2500Overall Heightmm3350Wheel Basemm4425+1350Trackmm2074/1834/1834Total vehicle mass in travel configurationkg31750Axle load   Front axlekg6550Rear axle25200Engine Model SC8DK280Q3Engine rated powerkw/(r/min)206/2200Engine rated torqueN.m/(r/min)1112/1400Max. travel speedkm/h80Min. turning diameterm22Min. ground clearancemm275Max. grade ability%40Approach angle°16Departure angle°13Braking distance (at 30 km/h, full load )m≤10Oil consumption per 100kmL≤37Exterior noise level during acceleration travelingdB (A)88Noise level at seated positiondB (A)90

2. Main Technical Data Table for Lifting Operation

DescriptionUnitParameter valueMax. total rated lifting capacityt50Min. rated working radiusm3Turning radius at turntable tailmm3800Max. load momentBase boomKN.m2009Fully-extended boom1129Outrigger spanLongitudinalm6.1Lateral7.1Hoist heightBase boomm11.9Fully-extended boom44Fully-extended boom + Jib58.1Boom lengthBase boomm11.4Fully-extended boom43.5Fully-extended boom + Jib59.5Jib offset angle°0, 15, 30Time for boom raisings≤40Time for boom extending fullys≤90Max. slewing speedr/min≥2.0Outrigger extending and retracting timeOutriggerExtendings≤35SimultaneouslyRetracting≤30SimultaneouslyOutriggerExtending≤40SimultaneouslyRetracting≤35SimultaneouslyHoisting speedMain winchNo loadm/min≥130(single lineAuxiliary winchNo load≥130Exterior noise leveldB (A)≤118Noise level at seated positiondB (A)≤90
