• Model NO.：RT55
• Type：Tower Crane
• Color：White
• Moving Type：Orbital
• Power Source：Hydraulic
• Sling Type：Wire Rope
• Installation：Assembled
• Tower Crane Type：Under Slewing Cranes
• Main Girder Form：Double Girder
• Transport Package：Main Machine Nude
• Specification：20days delivery
• Trademark：ZOOMLION
• Origin：China
• HS Code：87051022
• Production Capacity：30sets, Month

Basic Info.

Model NO. RT55 Type Tower Crane Color White Moving Type Orbital Power Source Hydraulic Sling Type Wire Rope Installation Assembled Tower Crane Type Under Slewing Cranes Main Girder Form Double Girder Transport Package Main Machine Nude Specification 20days delivery Trademark ZOOMLION Origin China HS Code 87051022 Production Capacity 30sets/ Month

Product Description

Zoomlion 55 Ton Rough Terrain Truck Crane (RT55)

Leading performance: The boom length in full extension is 39.5m, the performance leading in 5%. The grade ability is 40%, which make the machine have good road adaptability.
The unique U boom and plug-in boom head make the load-carrying capacity more balanced, and lift more smoothly.

The unique stretch and retract technique prevents the misoperation; The stretch and retract of the boom is safer and more reliable.

The control system is optimized by 8 patents; Lifting, rotation, and luffing are easy and reliable.
Six unique technologies supply the quality assurance, and make the products keep a high value.
The innovative jib system adopts embedded block, plug-in boom head and octagon jib, which has excellent lifting performance and safe and reliable lifting work.

The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.


Dimensions	Unit
Overall length	Mm	12500
Overall width	Mm	2500
Overall height	Mm	3385
Weight
Dead weight in travel state	Kg	32000
Front axle load	Kg	6800
Rear axle load	Kg	24800
Power
Engine model		SC9DF300Q3 WD615.329
Engine rated output	Kw(r/min)	221/2200 213/2200
Engine rated torque	N.m(r/min)	1250 1160
Travel
Max.travel speed	Km/h	80
Min. turning diameter	M	≤22
Min. ground clearance	Mm	275
Approach angle	.	18
Departure angle	.	13
Max. gradeability	%	40
Fuel consumption of per 100km	L	37
Lifting performance
Max. total rated lifting load	T	25
Min. rated working radius	M	3
Turning radius at swing table tail	Mm	3260
Base boom max. load moment	Kn.m	961
Base boom	M	10.4
Full-extend boom	M	40
Full-extend boom+Jib	m	48.3
Outrigger longitudinal distance span	M	5.36
Outrigger lateral distance span	M	6.0
Working speed
Boom elevating time	S	68
Boom telescoping time	S	150
Max. slewing speed	r/min	2.5
Main winch max. speed(single line)	m/min	120
Auxiliary winch max.speed(single line)	m/min	120

*********************************************************************************
