• Model NO.：QY80K
• Type：Gantry Crane
• Max. Travel Speed：85 Km,H
• Engine Rated Output：158,2200 Kw,(R,Min)
• Max. Total Rated Lifting Capacity：80 Ton
• L*W*H：14550*2750*3750
• Power Source：Hydraulic
• Sling Type：Wire Rope
• Application：Construction Usage
• Transport Package：Suitable for Ocean Shipment
• Specification：CE Certification, ISO
• Trademark：EVANGEL
• Origin：Jiangsu, China
• HS Code：87051092
• Production Capacity：30sets, Month

ItemUnitParameterOutline dimensionOverall lengthmm14550Overall widthmm2750Overall heightmm3750Wheel baseAxle 1, Axle 2mm1520Axle 2, Axle 3mm2600Axle 3, Axle 4mm1600Axle 4, Axle 5mm1350Axle 5, Axle 6mm1350TrackAxle 1, Axle 2, Axle 3mm2300Axle 3, Axle 4, Axle 5mm2055MassTotal mass in travel statekg60000Travel performanceTravel speedMax. travel speedkm/h85Min. stable travel speedkm/h4Turning radiusMin. turning radiusm13Min. turning radius at boom tipm15Min. ground clearancemm270Approach angle(° )19Departure angle(° )20Braking distance (at 30km/h with full load)m≤ 12Max. grade-abilitypercent22Fuel consumption for 100kmL75PowerUpper engine rated outputkW/(r/min. )158/2200Upper engine rated torqueN. m/(r/min. )770/1540Upper engine rated speedrpm.2200
Main Technical Data for Lifting Operation
 ItemUnitParameterLifting performanceMax. total rated lifting capacityt80Min. rated working radiusm3Turning radius at turntable tailm4.35Max. load momentBase boomkN. m2669Fully extended boom + JibkN. m578.8Outrigger spanLongitudinalm6.6Lateralm7Lifting heightBase boomm11.1Fully extended boomm43Fully extended boom + Jibm60Jib offset angle°0, 15, 30Working speedMax. swing speedr/min1.6Hoist speed (single line at 4th layer)Main winchFull loadm/min55No loadm/min82Aux. winchFull loadm/min70No loadm/min86
