• Type：Folding
• Emission Standard Capacity：Euro 3
• Engine Model：Cummins
• Rated Power/Revolution Speed：275,2100 Kw, Rpm
• Max. Lifting Moment-Base Boom：2560.2 Kn
• Swing Speed：0~2 R,Min
• HVAC in up Cab：Cooling
• HVAC in Low Cab：Cooling and Heating
• Weight：46000kg
• Front Axle Load：20000kg
• Rear Axle Load：26000kg
• Transport Package：Regular Package
• Specification：14100*2750*3850
• Origin：China
• Production Capacity：500

CapacityMax. lifting capacity80tDimensionsOverall lengthxwidthxheight14100x2750x3850mmAxle distance-1,21520mmAxle distance-2,34400mmAxle distance-3,41350mmWeightOverall weight46tFront axle load20tRear axle load26tEngineRated power275KW/2100rpmTrated torque1550N.m/1200rpm



Travelling
 Max. traveling speed80km/hMin.turning radius12mMin.turning radius of boom head15.6mMin. ground clearance230mmApproach angle20°Departure angle12°Max. gradeability37%


Main PerformanceTemperature range- 30 ° - + 60 °Boom section5Boom shapeU-shapedMax. lifting moment-Base boom2560.2 kN·mMax. lifting moment-Full-extend boom1254.4 kN·mOutrigger span(Longitudinal/Transversal)6.1 x 7.6 mJib offset0 °, 15 °, 30 °Working SpeedMax. single rope lifting speed of main winch(no load)130 m/minMax. single rope lifting speed of auxiliary winch
(no load)130 m/minFull extend/retract time of boom120 / 130 sFull raise/lower time of boom80 / 80 sSwing speed0~2.0 r/minAirconditionHVAC in upcabCooling and HeatingHVAC in low cabCooling and Heating
