50ton (Qy50ka) Truck Crane for Construction Lifting 55m

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • Certification：ISO9001
  • Condition：New
  • Maximum Lifting Height：>40m
  • Maximum Lifting Weight：>16t
  • Shaft Number：3
  • Crane Jib：Five-Arm

Base Info

  • Model NO.：Qy50ka
  • Type：Straight Arm
  • Turning Radius at Turntable Tail：3800mm
  • Max. Total Rated Lifting Capacity：50t
  • Min. Rated Working Radius：3m
  • Overall Width：2780mm
  • Transport Package：Nude Package
  • Specification：20-150 Ton Truck Crane
  • Trademark：xc. mg
  • Origin：China
  • Production Capacity：1000pieces,Year

Description

DescriptionUnitParameter valueMax. total rated lifting capacityt50Min. rated working radiusm3Turning radius at turntable tailmm3800Max. load momentBase boomKN.m2009Fully-extended boom1129Outrigger spanLongitudinalm6.1Lateral7.1Hoist heightBase boomm11.9Fully-extended boom44Fully-extended boom + Jib58.1Boom lengthBase boomm11.4Fully-extended boom43.5Fully-extended boom + Jib59.5Jib offset angle°0, 15, 30Time for boom raisings≤40Time for boom extending fullys≤90Max. slewing speedr/min≥2.0Outrigger extending and retracting timeOutriggerExtendings≤35SimultaneouslyRetracting≤30SimultaneouslyOutriggerExtending≤40SimultaneouslyRetracting≤35SimultaneouslyHoisting speedMain winchNo loadm/min≥130(single lineAuxiliary winchNo load≥130Exterior noise leveldB (A)≤118Noise level at seated positiondB (A)≤9050ton (Qy50ka) Truck Crane for Construction Lifting 55m
