• Model NO.：QUY70
• Color：Yellow
• Export Markets：Global
• Main Boom：12~57
• Rated Power：153,2200 Kw,Rpm
• Transport Package：Nude
• Specification：CE
• Origin：Xuzhou, China
• HS Code：8426990000
• Production Capacity：500 Sets,Month

Item
 Value
 Remarks

Max. lifting capacity × Radiust × m
 70×3.8

Deadweight with basic boomt
 61

Main boom lengthm
 12~57

Fixed jib lengthm
 6~18

Max. lifting capacity of fixed jibt
 6.4

Offset angle of fixed jib°
 10,30

Max. length of main boom with fixed jib m
 42+18
  Max. speed of single rope on drum

Main winchm/min
 120
 The 4 th rope layer

Auxiliary winchm/min
 120
 The 4 th rope layer

Derricking winchm/min
 45
 The 4 th rope layer

Slewing speedrpm
 0~2.4

Traveling speedkm/h
 0~1.35

Gradeability%
 30

Ground pressureMPa
 0.074

Overall dimensions (L×W×H)m
 11.2×3.3×3.2
 Incl. mast, boom bottom section
 Engine

Rated power/ rotational speed

kW/rpm
 153/2200

Max. output torque/ rotational speedNm/rpm
 929/1300

Emission standard
 TIER 3

Crawler gauge × ground contact length × track shoe widthmm
 2540×5040×1000
 Crawler carrier retracted
 4000×5040×1000
 Crawler carrier extended
