• Model NO.：QY50KA
• Shaft Number：8
• Crane Jib：Five-Arm
• Type：Straight Arm
• Overall Length：13100mm
• Overall Width：<=2750mm
• Overall Height：3350mm
• Min. Turning Diameter：24m
• Max. Travel Speed：66km,H
• Min. Ground Clearance：285mm
• Engine Rated Output：206,2200kw,(R,Min. )
• Transport Package：Seaworthy Packing
• Specification：ISO, CE
• Origin：Jiangsu, China
• HS Code：87051091
• Production Capacity：50sets,Months

ItemUnitParameterOutline dimensionOverall lengthmm13100Overall widthmm≤2750Overall heightmm3350Wheel baseAxle 1, Axle 2mm1520Axle 2, Axle 3mm3815Axle 3, Axle 4mm1350MassTotal mass in travel statekg38580Axle loadFront axlekg12950Rear axlekg25630Travel performanceTravel speedMax. travel speedkm/h66Min. stable travel speedkm/h2.7Turning diameterMin. turning diameterm24Min. turning diameter at boom tipm26.8Min. ground clearancemm285Approach angle(°)16Departure angle(°)16Braking distance (at 30km/h with full load)m10Max. grade-ability%27Fuel consumption for 100kmL36PowerModel WD615.67AEngine rated outputkW/(r/min.)206/2200Engine rated torqueN.m/(r/min.)1100/1400Engine rated speedrpm.2200 ItemUnitParameterLifting performanceMax. total rated lifting capacityt50Min. rated working radiusm3Turning radius at turntable tailm≤3.485Max. load momentBase boomkN.m1764Fully extended boomkN.m823Fully extended boom + JibkN.m492.8Outrigger spanLongitudinalm5.65Lateralm6.6Lifting heightBase boomm10.75Fully extended boomm40Fully extended boom + Jibm55.8Working speedBoom raising times88Boom full extension times180Max. swing speedr/min2.0Hoist speedMain winchFull loadm/min≥85No loadm/min≥110Aux. winchFull loadm/min≥80No loadm/min≥110Noise limitCrane exterior noisedB (A)≤118At seated positiondB (A)≤90
