• Model NO.：QY35K
• Type：Straight Arm
• Total Mass in Travel State：36930kg
• Engine Model：Sc9dk320q3
• Fuel Consumption for 100km：30L
• Engine Rated Output：235 , 2200 Kw,(R,Min)
• Engine Rated Torque：1250 , 1400 N.M, (R,Min)
• Max. Travel Speed：75km,H
• Max. Total Rated Lifting Capacity：35t
• Base Boom Length：>10.5m
• Transport Package：Nude Packing
• Specification：12620*2500*3350mm
• Trademark：XCM, G
• Origin：China
• HS Code：8429119000
• Production Capacity：1000,Year

DimensionUnitQY35K5Overall lengthmm12620Overall widthmm2500Overall heightmm3350Weight  Total weight in travelkg36930Front axle loadkg12330Rear axle loadkg24600Power  Engine model SC9DK320Q3Engine rated powerkW/(r/min)235 / 2200Engine rated torqueN.m/(r/min)1250 / 1400Travel  Max. travel speedkm/h75Min. turning diameterm19.5Min. ground clearancemm260Approach angle°17Departure angle°15.7Max. grade ability%40Fuel consumption for 100kmL30Main performance  Max. rated total lifting capacityt35Min. rated working radiusmm3000Turning radius at turntable tailm3.055Max. lifting torquekN.m1200Base boomm10.5Fully extended boomm39.6Fully extended boom+ jibm54.6Longitudinal outrigger spanm5.35Lateral outrigger spanm6Working speed  Boom luffing times68Boom full extension times≤155Max. swing speedr/min≥2.5Max. speed of main winch (single rope)m/min≥130Max. speed of aux. winch (single rope)m/min≥130
