• Model NO.：Kb5.0
• Lifting Capacity：5.00t*2.0m
• Maximum Radius：16m*0.21t
• Max.Lifting Height：16.8m
• Hook up Speed：8m,Min
• Crane Arm Length：4.7m-16.5m
• Boom Angle/Time：0-80,24.5sec
• Walking Speed：0-2.5km , H
• Vehicle Weight：6000kg
• Transport Package：Wooden Case or Nude Package
• Specification：4950*1560*2235mm
• Trademark：KB
• Origin：China
• HS Code：8426491000
• Production Capacity：100 Units,Month

model

KB5.0 crawler crane

specifications

5.00t*2.0m

Maximum radius of homework

16m*0.21t

The largest ground lift

16.8m

The largest underground head

20.5M

Winding device

Hook up speed:

8 m/min (growth 16 m/min) 6 on the rope

Steel wire rope

Diameter of 9.3 mm * 92 m

Telescopic device

Crane jib form

5 Angle automatic segment

Crane arm length

4.7m-16.5m

Telescopic crane boom length/time

11.7m / 54sec

Rolling device

Boom Angle/time

0°-80°/ 24.5sec

Rotary device

Turning Angle/time

0 ° ~ 360 ° continuous / 2.1 RPM (growth rate of 2.5 RPM)

leg

Leg action form

Manual rotation, oil pressure, oil pressure grounding

Maximum out of range

5670mm*5510m*5030mm

Walking device

Walk way

Hydraulic motor drive, two pieces of stepless variable speed

Walking speed

0-2.5Km / h

Climbing ability

20 °

Crane earthing length * width * 2

1720mm*320mm*2

Ground pressure

35.6kpa(0.356kgf / cm2)

The motor

The power supply voltage

The standard AC380V

power

7.5KW

The engine

model

3TNV88-PFN(YANMAR)

displacement

1.642L

Maximum output power

21.2KW/2400min-1

Start the way

Electric start

Startup performance

-5°C-40°C

Use fuel/volume

Diesel / 45 l

Battery capacity

12V90AH

Safety device

Level, alarm device, abrupt stop button, torque limiter and trichromatic lamp

System voltage

DC12V

The vehicle size

Length * width * height

4950mm*1560mm*2235mm

The weight of the

The vehicle weight

6000Kg

10.65 meters boom

13.56 meters boom

16.50 meters boom

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

< 2.0

5.0

< 3.5

3.03

< 4

2.23

< 5

1.13

2.5

4.16

4.0

2.58

4.5

1.93

5.5

0.98

3.0

3.46

5.0

2.03

5.0

1.73

6.0

0.91

3.5

3.05

6.0

1.68

6.0

1.40

7.0

0.76

4.0

2.60

7.0

1.38

7.0

1.18

8.0

0.65

5.0

2.08

8.0

1.13

8.0

1.03

9.0

0.60

6.0

1.72

9.0

1.05

9.0

10.0

0.55

7.18

1.45

10.0

0.86

10.0

0.83

11.0

0.49

11.0

0.69

12.0

0.44

12.0

0.53

13.0

0.38

13.0

0.43

14.0

0.32

15.0

0.26

16.0

0.21
