China Brand Mini Crawler 1ton Spider Crane Kb1.0 for Narrow Space
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Max. Lifting Height：5.5m
- Rated Loading Capacity：1ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
- Model：Kb1.0 Mini Crawler Crane
Base Info
- Model NO.：KB1.0
- Lifting Capacity：0.995t*1.5m
- Maximum Radius：5.07m*0.2t
- Max.Lifting Height：5.5m
- Max.Lifting Depth：18m
- Hook up Speed：10 M,Min (2 Strands)
- Crane Arm Length：2.08m-5.5m
- Boom Angle/Time：0°-75°, 14sec
- Walking Speed：0-3.2km , H
- Vehicle Weight：1230kg
- Transport Package：Wooden Case or Nude Package
- Specification：2140*600*1413mm
- Trademark：KB
- Origin：China
- HS Code：8426491000
- Production Capacity：100 Units,Month
Description
model
KB1.0 mini crawler crane
specifications
0.995T*1.5M
Maximum radius of homework
5.07M*0.2T
The largest ground lift
5.5M
The largest underground head
18M
Winding device
Hook up speed:
10 m/min (2 strands)
Steel wire rope
Diameter of 7.7 mm * 48 m
Telescopic device
Crane jib form
Five Angle automatic four segments
Crane arm length
2.08m-5.5m
Telescopic crane boom length/time
3.42m / 12sec
Rolling device
Boom Angle/time
0°-75°/ 14sec
Rotary device
Turning Angle/time
Continuous / 0 ° ~ 360 ° 40 SEC
leg
Leg action form
The first paragraph automatically, high-centralized section of the manual regulation
Maximum out of range
3600mm*3200mm
Walking device
Walk way
Hydraulic motor drive, two speed
Walking speed
0-3.2Km / h
Climbing ability
20°
Crane earthing length * width * 2
960mm*180mm*2
Ground pressure
35.6kpa(0.356kgf / cm2)
he engine
model
Honda GX270
displacement
270ml
The rated power output
5.1Kw / 1800rpm
Start the way
Motor start
Use fuel/volume
Gasoline / 6 l
Safety device
Level, alarm device, abrupt stop button
System voltage
DC12V
The vehicle size
Length * width * height
2140mm*600mm*1413mm
The weight of the
The vehicle weight
1230Kg
3.22 meters boom
4.36 meters boom
5.5 meters boom
Radius of homework
(m)
Total rated lifting weight
(t)
Radius of homework
(m)
Total rated lifting weight
(t)
Radius of homework
(m)
Total rated lifting weight
(t)
Radius of homework
(m)
Total rated lifting weight
(t)
<1.5
1.0
<1.5
1.0
<1.8
0.85
<2.5
0.65
1.65
0.92
2.0
0.8
2.0
0.8
3.0
0.53
2.5
0.65
2.5
0.65
3.5
0.4
2.79
0.56
3.0
0.53
4.0
0.32
3.5
0.41
4.5
0.27
3.93
0.33
5.0
0.21
5.07
0.2
