• Model NO.：KB3.0
• Lifting Capacity：2.95t*1.3m
• Maximum Radius：8.3m*0.14t
• Max.Lifting Height：9.2m
• Hook up Speed：6.5m,Min (4 Strands)
• Crane Arm Length：2.56m-8.92m
• Boom Angle/Time：0-75,14sec
• Walking Speed：0-2.9km , H
• Vehicle Weight：2050kg
• Transport Package：Wooden Case or Nude Package
• Specification：2900*800*1450mm
• Trademark：KB
• Origin：China
• HS Code：8426491000
• Production Capacity：100 Units,Month

Model

KB3.0 mini crawler crane

specifications

2.95T*1.3M

Maximum radius of homework

8.3M*0.14T

The largest ground lift

9.2M

The largest underground head

~

Winding device

Hook up speed:

6.5 m/min (4)

Steel wire rope

Diameter of 7.7 mm * 45 m

Telescopic device

Crane jib form

Five blocks of fully automatic

Crane arm length

2.56m-8.92m

Telescopic crane boom length/time

6.36m / 26sec

Rolling device

Boom Angle/time

0°-75°/ 14sec0°-75°/ 14sec

Rotary device

Turning Angle/time

Continuous / 0 ° ~ 360 ° 40 SEC

Leg

Leg action form

The first paragraph automatically, high-centralized section of the manual regulation

Maximum out of range

3900mm*3750mm

Walking device

Walk way

Hydraulic motor drive, two speed

Walking speed

0-2.9Km / h

Climbing ability

20 °

Crane earthing length * width * 2

1010mm*200mm*2

Ground pressure

51kpa

Diesel engine (optional)

Model

2TNV70-PYU

displacement

570ml

The rated power output

77.5Kw

Start the way

Electric start

Use fuel/volume

11L

The aerodynamic performance

5°C-40°C

Battery capacity

12V 45Ah

Gasoline engine

Model

GX390

displacement

389.2ml

The rated power output

6.6Kw

Start the way

Manual recoil start/electric start

Use fuel/volume

Gasoline / 6 l

The aerodynamic performance

-5°C-40°C

Battery capacity

12V 36Ah

The motor

Voltage power supply

The standard AC380V

power

4KW

The wireless remote control

Model

BOX1.1 (optional)

The effective distance

M100M

Waterproof standard

IP67IP67

Safety device

Level, alarm device, abrupt stop button, torque limiter (height limiter)

System voltage

DC12V

The vehicle size

Length * width * height

2900mm*800mm*1450mm

The weight of the

The vehicle weight

2050Kg

5.8 meters boom

7.34 meters boom

5.5 meters boom

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

Radius of homework

(m)

Total rated lifting weight

(t)

< 1.3

3.0

< 2.90

1.25

< 3.60

0.83

< 4.0

0.55

1.5

2.58

3.0

1.22

4.0

0.72

4.5

0.44

2.0

2.20

3.5

0.97

4.5

0.58

5.0

0.34

2.5

1.65

4.0

0.77

5.0

0.48

5.5

0.30

3.0

1.23

4.5

0.61

5.5

0.43

6.0

0.27

3.5

0.97

5.0

0.53

6.00

0.37

6.5

0.23

3.64

0.90

5.2

0.50

6.50

0.32

7.0

0.2

6.75

0.29

7.5

0.18

8.0

0.15

8.3

0.14
