8 Ton Qy8b. 5 Mini Truck Crane

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Type：Small Crane
  • Max. Rated Lifting Weight：8 Ton
  • Max. Height of The Main Boom：19 M
  • Height of The Basic Boom：8.2 M

Base Info

  • Model NO.：QY8B. 5 truck crane
  • Max. Height of Boom and Jib：25.3m
  • Rated Power/Rotate Speed：105kw,2500rpm
  • Tower Crane Type：Under Slewing Cranes
  • Main Girder Form：Single Girder
  • Moving Type：Car Type
  • Transport Package：Nude Packing
  • Specification：CE, ISO9001
  • Origin：Jiangsu, China
  • HS Code：8428909090
  • Production Capacity：500 Set,Sets , Month

Description

DimensionUnitQY8B.5Overall lengthmm9450Overall widthmm2400Overall heightmm3180Weight  Total weight in travelkg10490Front axle loadkg2800Rear axle loadkg7690Power  Engine model YC4E140-30Engine rated powerkW/(r/min)105/2500Engine rated torqueN.m/(r/min)500/1600Travel  Max. travel speedkm/h75Min. turning diametermm16000Min. ground clearancemm260Approach angle°29Departure angle°11Max. grade ability%28Fuel consumption for 100kmL25.5Main performance  Max. rated total lifting capacityt8Min. rated working radiusm3Turning radius at turntable tailm2.254Max. lifting torqueKN.m245Base boomm8.2Fully extended boomm19Fully extended boom+jibm25.3Longitudinal outrigger spanm3.825Lateral outrigger spanm4.18Working speed  Boom luffing times28Boom full extension times31Max. swing speedr/min2.8Main winch single-pump/dual-pump converging (single rope)m/min53/110
