• Model NO.：Howo
• Transport Package：Nude Packing
• Specification：11250x2550x3850mm
• Trademark：sinotruk
• Origin：China
• HS Code：83269100
• Production Capacity：5000pieces,Year

BodyCarriage Internal Dimensions(mm)6400x2326x600Cubage (m3)8.93Steel thickness of Carriage(mm)Floor:3mm/Side:1.5mmSteelQ235Weight in kgKerb weight (Kg)16050Gross vehicle weight (Kg) 25000Dimension(mm)Dimensions(mm)Length(mm)11250Width(mm)2550Height(mm)3850Wheel base (mm)4600+1350PerformanceMaximum driving speed (km/h)  92Fuel consumption  (1/100 km)35CabModelSINOTRUK HW76  Lengthen cabsingle bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO
instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,right driving,air conditionerEngineModelWD615.69(Euro II)Type6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injectionHorsepower336Maximum output Kw/r/min247/2200Maximum torque N.m/r/min1350/1300-1600Bore x Stroke126x130mmValve2Displacement9.726LMake SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80ºC opening begin, Rigid fanTransmissionSINOTRUK HW19710 transmission ,10 forward and 2 reverseClutchSINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistanceSteeringZF8118 Steering Gear Box ,hydraulic steering with power assistance.(left hand driving)Front AxleSINOTRUK HF7 Front Axle,new 7-ton front axles of equipped with drum brakes.Rear AxlesSINOTRUK ST16 Double Reduction Drive Axle, Pressed axle housing, central single reduction with planetary wheel
reduction and with differential locks between wheels and axles,ratio:4.42;strengthened design,
loading capacity and reliability have been increased greatly.Brake SystemService brake:dual circuit compressed air brake
Parking brake (emergency brake):spring energy,compressed air operating on rear wheelsWheels & TyresRims:10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.ElectricsOperating voltage:24V,negative grounded
Starter:24V,7.5 Kw
Alternator:3-phase,28V,1500 W
Batteries:2x12 V,165 Ah
horn,headlamps,fog lights,brake lights,indicators and reverse light.Oil TankSquare type-400L Aluminum alloy fuel tank


company information

1 Factory price, more competitive than agent price.
2 Quality: With SINOTRUK group inspection system, a series inspections are well done before the exportation.
3 Warranty: One year or 100 000k which comes to the first for the engine, gear box, and axles.
4 After-sales: Professional after-sales team sovle your difficult or special questions within 3 working days or 5 working days, and all spare parts are available for your urgent use.
5 Transportation: Professional logistics team work with international shipping company for your truck shipment successfuly.

Certifications

Heavy Trucks on board for shipping


Our Services

1. Factory direct supply: reliable quality and fast delivery;

2. Warranty; from the date of receiving, in normal use within 30000kh or within one year, we will repair for free, but the wearing parts and electrical parts are not included. After one year, we only charge cost when the question occurs;

3. Tracking service: lifelong

4. Chassis question: when the question occurs, please find the local nearest Service Station for repair or maintenance, or call us if the local have no Chassis Service Station;

5. Spare Parts: Superstructure spare parts is sent by ourselves, we only charge cost; Chassis spare parts is sent by the local Service station, if the local have no chassis service station, please call us freely.

6. OEM Ability: We can customize the truck according to your request, such as material, size, color, paint, logo, etc.

7. Warm tip: please operate, use, and maintain the truck according to our manuals and Instructions. When the question occurs, please call us freely.
