• Model NO.：QY70K-I
• Shaft Number：4
• Crane Jib：Five-Arm
• Type：Folding
• Product Name：70 Ton Truck Mounted Crane Heavy Duty Crane Truck
• Model：Qy70K
• Rated Load：70 Ton
• Transport Package：Nude Package
• Specification：70 Ton
• Trademark：Top brand
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000 Units,Month

Basic Info.

Model NO. QY70K-I Shaft Number 4 Crane Jib Five-Arm Type Folding Product Name 70 Ton Truck Mounted Crane Heavy Duty Crane Truck Model Qy70K Rated Load 70 Ton Transport Package Nude Package Specification 70 Ton Trademark Top brand Origin Jiangsu, China HS Code 8705109100 Production Capacity 10000 Units/Month

Product Description

70 Ton Truck Mounted Crane Heavy Duty Crane Truck QY70K-I

The innovative jib system adopts embedded block, plug-in boom head and international advanced U section jib, which has excellent lifting performance and safe and reliable lifting work.

• The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.

• Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.

• Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.

• The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.

• The humanity design makes the cab and control cab more spacious, and easy to operate.

• Six unique manufacturing technologies ensure the high quality.



Main Parameter

Dimension	Unit	QY70K-I
Overall length	mm	13930
Overall width	mm	2800
Overall height	mm	3575
Weight
Total weight in travel	kg	43000(without 1t vice counterweight)
Front axle load	kg	17000
Rear axle load	kg	26000
Power
Engine model		WD615.338(domestic III)
Engine rated power	kW/(r/min)	276/2200
Engine rated torque	N.m/(r/min)	1500/1400
