• Model NO.：Qy12D451
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Folding
• Max. Lifting Height：29.8m
• Rated Loading Capacity：12000kg
• Lifting Moment of The Longest Boom：258.77kn,M
• Boom Time：38s
• Maximum Travel Speed：80km,H
• Minimum Turning Diameter：≤20m
• Rated Lifting Moment：465.5kn,M
• Speed of Single Rope of Main Winch：98m,Min
• Maximum Rotation Speed：2.2r,Min
• Maximum Gradient：40%
• Total Mass：19450kg
• Transport Package：None
• Specification：11150*2500*3180mm
• Trademark：ZOOMLION
• Origin：Hunan China
• Production Capacity：200units,Month

ItemValueRemarksWorking performance specification rated total lifting capacity kg12000  load moment of basic boom kN.m465.5  load moment with main boom length kN.m258.7 lifting height of main boom m29.8Deformation of boom is not taken into consideration.lifting height of fly jib m35.8Working speedspeed of single rope on main winch m/min98The 4^th layer of drumspeed of single rope onauxiliary winch m/min87 Telescopic time of boom s53.5 Derricking time of boom s38 Slewing speed r/min0~3 Traveling specification traveling speed km/h78 gradeability %27.5 Min. turning circle diameter m18 Min. ground clearance mm260 Limits for exhaust pollutants and smokeComply with related standardsGB3847-2005GB17691-2005(Stage III)Oil consumption per hundred kilometers L28 Mass specificationDeadweight of crane in traveling condition kg18030 Complete vehicle kerb mass kg17900 Front axle load kg5120 Rear axle load kg12910 Dimension specificationOverall dimensions(L×W×H)mm11000×2500×3180 Base on outriggers m4.63 Distance between outriggers m5.2 Main boom length m9.2~29.4 Main boom angle °-2~80 Fly jib length m6 Offset angle of fly jib °0 ChassisModelZLJ5241 ClassII EngineModelWP6.210 Rated power kW/r/min155/2300 output torque N.m/r/min750 /1400~1500 ManufacturerChangsha Zoomlion Heavy Industry Science & Technology Development Co., Ltd
