China Brand New 70 Ton Truck Crane in Stock
Evangel Industrial (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
- Shaft Number：3
- Crane Jib：Five-Arm
Base Info
- Model NO.：QY70
- Type：Folding
- Engine Brand：Wd615.338
- Transport Package：Nude Package
- Specification：13930*2800*3575mm
- Trademark：EVANGEL
- Origin：China
Description
Dimension
Unit
QY70K
Overall length
mm
13930
Overall width
mm
2800
Overall height
mm
3575
Weight
Total weight in travel
kg
43000(without 1t vice counterweight)
Front axle load
kg
17000
Rear axle load
kg
26000
Power
Engine model
WD615.338(domestic III)
Engine rated power
kW/(r/min)
276/2200
Engine rated torque
N.m/(r/min)
1500/1400
Travel
Max. travel speed
km/h
80
Min. turning diameter
m
24
Min. ground clearance
mm
327
Approach angle
°
19
Departure angle
°
13
Max. grade ability
%
40
Fuel consumption for 100km
L
45
Main performance
Max. rated total lifting capacity
t
70
Min. rated working radius
m
3000
Turning radius at turntable tail
m
3.55
Max. lifting torque
kN.m
2303
Base boom
m
11.6
Fully extended boom
m
44.5
Fully extended boom+ jib
m
59.5
Longitudinal outrigger span
m
6.1
Lateral outrigger span
m
7.3
Working speed
Boom luffing time
s
60
Boom full extension time
s
≤150
Max. swing speed
r/min
≥2.0
Max. speed of main winch (single rope) (no load)
m/min
≥130
Max. speed of aux. winch (single rope) (no load)
m/min
≥108
